| Processor | Supports 1 or 2 of a 1st or 2nd Gen Intel? Xeon? Scalable Processor CPU TDP：Up to 205W Max. 28 cores per processor |
| Chipset | Intel? C621 Chipset |
| System Bus | 3 UPI links at up to 10.4 GT/s |
| ?Memory | Supports 16 DDR4 memory slots Max. capacity：Up to 4TB using 3DS ECC LRDIMM/RDIMM Max. speed：2933 MT/s |
| Local Storage | Local Storage |
| RAID Supports | Supports RAID0, RAID1, RAID10, and RAID5 (Supported under Windows only) Optional supports for RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60, etc., with cache supercapacitor protection and features Supports RAID level migration, hot spare, and online capacity expansion |
| Network | Supports 2 Intel? X550 10GbE network ports Supports 1 Gigabit remote management interface Optional configurations include dual Gigabit/10GbE, quad Gigabit/10GbE,and 25Gb Ethernet cards, among others |
| Graphics Display | Onboard display chip (VGA). |
| Optical Drive | Optional external USB DVD-RW drive |
| PCI-E Expansion | 4*PCI-E 3.0 x16 slots (full-height dual-slot; controlled by CPU1：slots 2 & 4, CPU2：slots 6 & 8) 2*PCI-E 3.0 x16 slots (full-height single-slot; controlled by CPU1：slot 9, CPU2：slot 10) 1*PCI-E 3.0 x8 slot (full-height single-slot with x4 bandwidth; controlled by CPU2：slot 11) |
| I/O Interfaces | Front Panel： 2*USB 2.0 Rear Panel： 1*RS232 COM 1*RJ45 Gigabit remote management port 2*USB 3.0 2*USB 2.0 2*RJ45 10GbE network 1*VGA |
| System Fans | Supports 3*hot-swappable 12038B roller fans Optional |
| OS Supports | Windows 8.1/10 64bit Windows Server 2012 R2/2016/2019 64bit RedHat Enterprise Linux Server 7.3/7.4/8.1/8.2 64bit CentOS 7.3/7.4/8.1/8.2 64bit Ubuntu 18.04/20.04 64bit VMWare ESXi 6.5 U1 |
| Environment | Operating Temperature |
| Power Supply | 2000W 1+1 redundant power supply, 80PLUS Platinum (Input |
| Dimensions (W*H*D) | 650*437.5*176.5（mm） |
| Model No. | Description |
| EIS-H4205RG-01 | (4U Dual-socket High-Performance 4*GPU Supercomputing Server) Supports 1 or 2 of Intel Xeon Scalable Series processor or, 1 or 2 of a second Gen Intelligent Intel Xeon Scalable processor / X11DPG-QT / C621 Chipset / 16*DDR4 memory slots / 8* hot-swappable 3.5" drive bays / 1*built-in M.2 PCI-E SSD slot / 2*10GbE network ports / 1*Gigabit management port / 1*VGA port / 6*PCI-E 3.0 x16 slots (supports up to dual-width 4*GPUs) / 1*PCI-E 3.0 x4 slot / 2*COM ports (one available as an option) / 2000W 1+1 redundant power supply |
