Monitor | 23.8" |
Resolution | 1920*1080 |
Brightness | 250cd/㎡(Typ.) |
Viewing Angle | 89/89/89/89(Typ.)(CR≥10) |
Touchscreen | 10-Point Industrial-Grade Capacitive Touchscreen |
Processor | Default: I5-1155G7 (Base frequency 1.0GHz~4.5GHz,4 cores,8 threads) Optional: I7-1165G7 (Base frequency 1.2GHz~4.7 GHz,4 cores,8 threads) I3-1115G4 (Base frequency1.7GHz~4.1 GHz,2 cores,4 threads) 6305E (Base frequency1.8GHz,2 cores,2 threads) |
Chipset | MCU |
BIOS | AMI UEFI |
Memory | 2*SO-DIMM,DDR4 3200MHz,up to 64G Default 1*8G DDR4 2666 laptop memory |
Display | Integrated Graphic |
Expansion Slot | Default: 1*M.2 (KEY-M,2280,supports SATA SSD) 1*M.2 (KEY-E,2230,PCIE+USB 2.0 signal,supports WiFi+BT) 1*M.2 (KEY-B,3052,PCIE/USB 3.0+USB2.0 signal,supports 5G+4G/3G) Optional 4-port Ethernet Ver.: No M.2 slot |
Ethernet | Default: 1*Intel I219 (10/100/1000Mbps,supports Wake On Lan) 1*Intel I225 (10/100/1000Mbps) Optional: 1*Intel I219 (10/100/1000Mbps,supports Wake On Lan) 1*Intel I225 (10/100/1000Mbps) 2*Intel I210 (10/100/1000Mbps) |
Drive Bay | Default 2-port Ver.: 1*M.2 (KEY-M, 2280, SATA SSD) 1* 2.5” drive bay (Default:M.2 SATA SSD 128GB) Optional 4-port Ethernet Ver.: 1* 2.5” drive bay |
I/O Interface | 2* HDMI Default 2-port Ver.: 6*COM (default:6*RS232,COM6 optional RS232/485) Optional 4-port Ethernet Ver.: 2*COM (default:2*RS232) 6*USB 3.0 1*3.5mm Audio jack(Line-Out + MIC 2 in1) 1* Remote Switch,1*SIM slot 1*DC Power connector (Threaded) |
Operating Temperature | -10℃ to 50℃, 5% to 95% (non-condensing) |
Storage Temperature | -20℃ to 60℃, 5% to 95% (non-condensing) |
Power Supply | DC 12V,default 12V 120W power adapter |
ESD | Contact 6Kv,Air Gap 8Kv |
Vibration Resistance | GB/T2423.10 |
Protection Rating | Front panel complies with IP65 dust and waterproof |
Chassis Material | Aluminum-magnesium alloy, galvanized steel |
Mounting | Panel Embedded,Wall mount,VESA Standard mount |
OS Support | Windows? 10/linux |
Dimension(W*H*D) | 582.5*354.5*85.5(mm) |
Weight(KG) | 8.48(KG) |
Model No. | Description |
PPC-HW2362NBCT | (J1900,6*COM + 6*USB) 23.8" Fanless Industrial Touch Screen Panel PC / 1920*1080 / EC3-T1962L-A|EC3b-H1962L-H / J1900 / DDR3L 4G (Onboard 1 slot DDR3L laptop memory,up to 8GB) / 1Msata,1*2.5” drive bay,default 128G Msata / 2*LAN (2*Intel I211/I210 chips) / defualt 6*RS232 (COM5 supports RS232/TTL, COM6 supports RS232/RS485) / 1*HDMI, 1*VGA / 1*USB3.0, 5*USB2.0 / 1*MIC in, 1*Line out / 1*MINI PCIE (Optional supports WiFi or 4G function) / default 12V5A 60W power adapter / Wall-mounted, Embedded / Windows 10/8/7/ Linux |
PPC-HW2362NBCT-04 | (I7-4600U, 6*COM + 6*USB) 23.8" Fanless Industrial Touch Screen Panel PC / 1920*1080 /EC3-T4662-I / I7-4600U / 4G (Onboard 1 slot DDR3L laptop memory, up to 8G) / 1*Msata, 1*2.5” drive bay, default 128G MSATA SSD / 2*USB3.0, 4*USB2.0 / 1*VGA / Default 6*RS232 (COM1 optional RS232/485, COM2 optional RS232/422/485) / 2*LAN (Intel i211) / Line-Out, MIC-In / 1*Mini PCIE (sOptionally supports WiFi and BT) / DC12V-24V 60W power adapter / Wall-mounted, Embedded / Windows 10/8/7/2008/ Linux. |
PPC-HW2362NBCT-09 | 23.8" Fanless Industrial Touch Screen Panel PC / 1920*1080 / EC3-T6462L-A / J6412 / 8GB (1*SO-DIMM Slot, DDR4 2666/2933/3200MHz, up to 32GB) / 1*2.5” drive bay, 1*M.2 (Key-M, 2280, PCIe x2 NVME SSD), default 128GB SSD / 2*HDMI / 2*LAN (2*Intel I225-V) / 3*USB3.0, 3*USB2.0 / 6*COM (Default 6*RS232, COM6 optional RS485) / 1*audio Line-Out+MIC combo (CTIA international standard) / 1*Power button, 1*SIM slot / 1*M.2 (Key-B, 3052, USB3.0+USB2.0 supports 5G module, 4G module requires an adapter card, Optionally), 1*MPCIE (full height, PCIe+USB2.0, supports WiFi+BT) / 1*DC power supply connector (with threads) / Default DC12V input (with a 12V 60W power adapter) / Embedded, Wall mount, VESA mount/ Windows 10/Linux |
PPC-HW2364NBCT-10 | 23.8" Fanless Industrial Touch Screen Panel PC / 1920*1080 / EC8-T31C64-A / H310C chipset / I7-8700 / 8GB (2*DDR4 SO-DIMM, up to 32GB) / 1*2.5", 1*M.2 (Supports SATA SSD), default 128GB SSD / 4*LAN (Intel219+Intel210+2*Intel226) / Default 6RS232 (COM1-2 optional RS232/RS422/RS485) / 4*USB3.0+4*USB2.0 / 1*HDMI / 1*VGA / 1*Backup button/1*Restore button/1*Remote-Switch /8*GPIO (4*GPI+4*GPO, external power supply, supports 5V-24V) / 1*SIM / 1*M.2 (Key-B, 3042/3052, supports 4G, 5G) / 1*M.2 (Key-M, 2280, supports SATA SSD) / 1*MPCIE (full-height, PCIe+USB2.0 signal, supports WiFi/BT) / DC12V-24V, default 19V 123W power adapter / Embedded, Wall mount, VESA mount |
PPC-HW2362NBCT-11 | 23.8" Fanless Industrial Touch Screen Panel PC /1920*1080 / EC3-TB562L-A4 / i5-1155G7 / DDR4 8GB (onboard 2*DDR4 slots, up to 64GB) / 1*M.2 (Key-M, 2280, SATA SSD signal), default M.2 128GB SSD / 1*M.2 (KEY-E, 2230, PCIe+USB2.0 signal, supports WiFi+BT) / 1*M.2 (KEY-B, 3052, PCIe/USB3.0+USB2.0 signal, supports 5G/4G modules) / 6*USB3.0 / 6*RS232 (COM6 optional RS232/485) / 2*LAN (1*Intel I225+1*Intel I219) / 2*HDMI / Default 12V5A 60W power adapter / Wall-mount. |
