| Processor | Supports 65W or lower 10th/11th Gen Intel Core i7/i5/i3 (LGA 1200). Standard specs：Intel Core i5-10400T (Base 2.0 GHz,Turbo 3.6 GHz,6-core/12-thread). |
| 35W CPU | Supports 10th/11th Gen low-power i3/i5/i7. |
| Chipset | H470 |
| BIOS | AMI UEFI |
| ?Display | Integrated graphics (VGA + HDMI + DP) |
| Memory | 2*SO-DIMM Slots,DDR4 2400,up to 32GB. Standard specs：8GB DDR4 2666 notebook memory,dual-channel. |
| Drive Bay | 1*M.2 (KEY-M, 2280, PCIEx4 NVME and SATA adaptable). 1*2.5" HDD slot (7mm/15mm). Standard specs：1*128GB SSD. |
| Ethernet | 1*Intel I219 (10/100/1000Mbps,supports Wake-on-LAN). 3*Intel I210 (10/100/1000Mbps adaptive Ethernet). |
| Expansion Slots | 1*M.2 (KEY-B,3042/3052,PCIe+USB3.0 supports 4G/5G modules). 1*MINI PCIe (full height,PCIe+USB2.0 signals,supports WiFi/BT). |
| I/O Interface | 1* VGA,1* HDMI,1*DP,4*LAN 6*COM (Standard specs：6*RS232,COM1-2 supports RS232/422/485,COM6 supports RS232/TTL) 4*USB3.0,4*USB2.0 Supports T-MOD module expansion (2*RJ45/2*CAN/12*DI+12*DO optional) Audio：1*MIC in,1*Line out,1*Line in 1*Power button,1*Restart button,1*Remote switch,1*Restore button,1*Backup button,1*SIM slot 1*DC IN |
| ?Operating Temperature | -10°C ~ 60°C,5%~95% (non-condensing) |
| Storage Temperature | -20°C ~ 75°C,5% ~ 95% (non-condensing) |
| ?Power Supply | DC12~24V,standard specs：19V 123W power adapter |
| ESD | Contact 6kV,Air 8kV |
| Vibration Resistance | GB/T2423.10 |
| Chassis Material | Aluminum-magnesium alloy,galvanized steel |
| Mounting | Wall mount,VESA standard |
| OS Support | Windows 10/Ubuntu 18.04 or above/CentOS 8 or above/Linux (Kernel version 4.15 or above) |
| Dimensions (W*H*D) | 220*240*80mm |
| Weight (KG) | 2.6(KG) |
