◆Aluminum-magnesium Alloy
◆Intel® Core? 6th/7th/8th/9th Gen
◆1* HDMI,1*VGA,6*COM,4*LAN ,8*USB
◆-10 ~ 60℃ Extend Temperature Operating
| Processor | Supports 65W or lower 6th/7th/8th/9th Gen Intel Core i7/i5/i3 (LGA 1151). Standard specs：Intel Core i5-6500(Base frequency 3.2 GHz, Turbo Boost 3.6 GHz, 4 Cores, 4 threads ) |
| 65W CPU | Supports 6th/7th/8th/9th Gen desktop i3/i5/i7 CPU (?e.g. i3-6100, i5-7400, i7-8700, i5-9400) |
| Chipset | H110 |
| BIOS | AMI UEFI |
| ?Display | Integrated graphics (VGA + HDMI + DP) |
| Memory | 2*SO-DIMM Slots, DDR4 2400, up to 32GB. Standard specs：8GB DDR4 2666 laptop memory, dual-channel. |
| Drive Bay | 1*M.2 (KEY-M, 2280, PCIEx4 NVME and SATA adaptable) 1*2.5" drive bay (7mm/15mm) Standard specs |
| Ethernet | 1*Intel I219 (10/100/1000Mbps, supports Wake-on-LAN). 3*Intel I210 (10/100/1000Mbps adaptive Ethernet). |
| Expansion Slots | 1*M.2 (KEY-B, 3042/3052, PCIe+USB3.0, supports 4G/5G modules) 1*MINI PCIe (full height, PCIe+USB2.0, supports WiFi module) 1*PCIEx16 (x8 signal) 1*PCIEx4 (x4 signal) |
| I/O Interface | 1* VGA 1* HDMI 1*DP 4*LAN 6*COM (Standard specs |
| ?Operating Temperature | -10°C ~ 60°C, 5%~95% (non-condensing) |
| Storage Temperature | -20°C ~ 75°C, 5% ~ 95% (non-condensing) |
| ?Power Supply | DC12~24V, standard specs |
| ESD | Contact 6Kv, Air Gap 8Kv |
| Vibration Resistance | GB/T2423.10 |
| Chassis Material | Aluminum-magnesium alloy, galvanized steel. |
| Mounting | Wall mount, VESA standard |
| OS Support | (6th/7th Gen CPU) Windows 7/8/10/Ubuntu 18.04 or above/CentOS 8 or above/Linux (Kernel version 4.15 or above) (8th/9th Gen CPU) Windows 10/Ubuntu 18.04 or above/CentOS 8 or above/Linux (Kernel version 4.15 or above) |
| Dimensions (W*H*D) | 220*240*150(mm) |
| Weight (KG) | 4.6（KG） |
