| Processor | Supports 65W or lower 6th/7th/8th/9th Gen Intel Core i7/i5/i3 (LGA 1151). Standard specs |
| 35W CPU | Supports 6th/7th/8th/9th Gen low-power i3/i5/i7 CPU (?e.g. i3-6100T, i5-6700T, i7-7700T, i5-8500T, i7-8700T, I7-9700T) |
| Chipset | H110 |
| BIOS | AMI UEFI |
| ?Display | Integrated graphics (VGA + HDMI + DP) |
| Memory | 2*SO-DIMM Slots, DDR4 2400, up to 32GB. Standard specs |
| Drive Bay | 1*M.2 (KEY-M, 2280, PCIEx4 NVME and SATA adaptable) 1*2.5" HDD slot (7mm/15mm) Standard specs |
| Ethernet | 1*Intel I219 (10/100/1000Mbps, supports Wake-on-LAN). 3*Intel I210 (10/100/1000Mbps adaptive Ethernet). |
| Expansion Slots | 1*M.2 (KEY-B, 3042/3052, PCIe+USB3.0, supports 4G/5G modules). 1*MINI PCIe (full height, PCIe+USB2.0 signals, supports WiFi/BT). |
| I/O Interface | 1* VGA 1* HDMI 1*DP 4*LAN 6*COM (Standard specs |
| ?Operating Temperature | -10°C ~ 60°C, 5%~95% (non-condensing) |
| Storage Temperature | -20°C ~ 75°C, 5% ~ 95% (non-condensing) |
| ?Power Supply | DC12~24V, standard specs |
| ESD | Contact 6Kv, Air Gap 8Kv |
| Vibration Resistance | GB/T2423.10 |
| Chassis Material | Aluminum-magnesium alloy, galvanized steel. |
| Mounting | Wall mount, VESA standard |
| OS Support | (6th/7th Gen CPU) Windows 7/8/10/Ubuntu 18.04 or above/CentOS 8 or above/Linux (Kernel version 4.15 or above) (8th/9th Gen CPU) Windows 10/Ubuntu 18.04 or above/CentOS 8 or above/Linux (Kernel version 4.15 or above) |
| Dimensions (W*H*D) | 220*240*80(mm) |
| Weight (KG) | 2.6（KG） |
