| Model | CGL-TPE1-H2P |
| PCIe | PCIE2.0 (2.5GT/s & 5.0GT/s) x4, compatible with x8, x16 |
| Controller Chip | 2*Intel?i210AT with 9.5KB jumbo frame support |
| Port Type | 2*8-Pin RJ45 |
| Port Rate | 10/100/1000Mbps；Max：1GbE |
| Cable Requirements | CAT2/3/4/5/6 cables |
| Power Consumption | Min：2.808W; Max：3.684W |
| Power Supply | PCIe bus power, 5W (max) power consumption |
| ESD | Contact discharge 6KV; air gap discharge 8KV |
| RSS Load Balancing | 4 queues per port |
| PXE | Support |
| UEFI | Support |
| DPDK | Support |
| 1588 PTP | Support |
| LED Indicator | Active (left) |
| Operating Temperature | -10°C ~ 60°C (14°F ~ 140°F) (Non-condensing) |
| Storage Environment | -20°C ~ 70°C (-4°F ~ 158°F) (Non-condensing) |
| Dimensions | PCB |
| Packing List | 1*Network Interface Card 1*Product warranty card |
