| Processor | Supports 2nd or 3rd Gen Intel LGA1155 processors. Standard configure：Intel Core i5-3470 (3.2 GHz, Quad-Core, 4 threads). |
| Chipset | B75 |
| BIOS | UEFI |
| Memory | 2* SO-DIMM DDR3L 1600 slots, max. 16GB. Standard configuration：1*8GB DDR3 1600 desktop memory. |
| Graphics Display | Intel? HD Graphics (VGA) |
| Expansion Slots | 1*full size mini pcie, supports WIFI 1*full size mini sata |
| Ethernet | 6* LAN 10/100/1000Mbps, supports Wake-on-LAN. |
| Drive Bay | 1* mSATA 3.5" or 2.5” drive bay. Standard configuration：1*128GB mSATA SSD. |
| I/O Interface | 1* VGA 6* LAN 10/100/1000Mbps (Intel i210 chipset) 1* RS232 COM (RJ45) Management port 2*USB2.0 1* Power button, 1* Reset button 1*Power LED 1*HDD LED |
| Operating Temperature | -10°C- 60°C, 5%–95% (non-condensing). |
| Storage Temperature | -20°C -70°C, 5%–95% (non-condensing) |
| Power Supply | AC100-240V |
| ESD | 4KV contact, 6KV air-gap ESD |
| Vibration Resistance | GB/T2423.10 |
| Chassis | High-quality galvanized steel |
| Mounting | Rack Mount |
| OS Supports | Windows? 7/XP/2008/Linux |
| Dimension(W*H*D) | 360 * 45 * 450 (mm) |
| Weight (KG) | 5(KG） |
| Model No. | Description |
| NIS-H7516 | Gateway Server / EC9-T7526-B / B75 Chipset / Intel Core i5-3470 / 8GB RAM (2x DDR3 SO-DIMM slots, max. 16GB) / 1* mSATA, 1*SATA, standard configuration |
